Bicycle Assembly

STEP 1: HANDLE

  • Rotate Stem to Front in Clockwise Direction
  • Recmove Bolts & cover from the stem
  • Put handle as shown. Front brake lever should be on right side.
  • Tighten the Nuts in Cross Fashion

STEP 2: WHEEL (QUICK RELEASE)

  • Open & instert Quick Release Axle in Wheel like shown, so that 1 spring is at each side of the Wheel.

STEP 2: WHEEL ( WITHOUT QUICK RELEASE)

  • Loosen the nuts as shown in the video.
  • Insert the wheel in the slot, so that the disc rotor goes inside the caliper.
  • Ensure the locking washer is in the slot as shown in the video. Tighten fully.

STEP 3: PEDAL (RIGHT)

  • Insert pedal market with (R) and right side (drive side), and rotate CLOCKWISE.

STEP 4: PEDAL (LEFT)

  • Insert pedal market with (L) and left side (non drive side), and rotate ANTI -CLOCKWISE.
