OMOBIKES

Bicycle Frame Aluminium Alloy | Multi Speed | Omobikes model Ladakh, Hampi

Bicycle Frame Aluminium Alloy | Multi Speed | Omobikes model Ladakh, Hampi

β‚Ή4,499
β‚Ή0 β‚Ή4,499
Sale Sold out
Taxes included. Shipping calculated at checkout.
Size

A lightweight, durable aluminum alloy frame designed for custom bicycle builds, upgrades and replacement.Β

Technical Specifications

Specification Details
Material Aluminum Alloy
Frame Weight Approx. 1,800 g
Wheel Compatibility 700c / 27.5" / 29"*
Brake Compatibility Mechanical / Hydraulic Disc Brakes
Drivetrain Compatibility Multi-Speed
Cable Routing Internal
Fork Compatibility Suspension / Rigid
Fork Steerer 1β…›" Straight, Threadless
Head Tube Straight
Bottom Bracket 68 Γ— 122 mm
Rear Hub Spacing 135 mm
Seatpost Diameter 27.2 mm
Maximum Tyre Clearance 2.1"
Bottle Cage Mounts 1 Bottle

*Wheel-size compatibility may vary by frame model/size. Please check the specifications for the selected variant before ordering.

What's Included

  • 1 Γ— Aluminum Alloy Frame
  • 4 Γ— Plastic Cable Guides
  • 1 Γ— Rear Derailleur Hanger
  • 1 Γ— Rear Derailleur Hanger Screw
  • 2 Γ— Bottle Cage Mounting Bolts
  • 1 Γ— Frame Cup

Compatibility: Please confirm your fork, wheels, bottom bracket, brakes, drivetrain and seatpost are compatible with the specifications above before ordering. If unsure, send us your component details or photos and we'll help you check compatibility.

Return, Refund & Cancellation Policy
View full details
  • 5 stars: 1 (100%)
  • 4 stars: 0 (0%)
  • 3 stars: 0 (0%)
  • 2 stars: 0 (0%)
  • 1 star: 0 (0%)
S
Shailesh Kulkarni
Hampi frame

The frame is excellent, but Omobikes have heart of gold. Frame had cracked, and they replaced the frame free of cost with delivery

V
Vinni

Hi,
Is it possible to get this frame along with rigid alloy fork (disc brake compatible)? and also with the derailleur hanger.
I am interested in buying the above 3 as a set. additionally can you also confirm the weight of the frame and fork.

omobikes

Yes alloy rigid fork is possible, Hampi model you can check on omo website for reference. The deraillure hanger can be attached to same , it is available . Frame and fork are disc brake compatible, You can send email to care@omobikes.com or drop message to whatsapp support team at 6205538323 to further queries. Weight of the frame is around 1.8KG
